Brand | magus |
garantie, jaren | 5 |
ean | 5905555018461 | < /tr>
pakketgrootte (lxwxh), cm | 49.5x34.5x68 |
Verzendgewicht, kg | < td> 19.25
kop | trinocular |
kop hellingshoek | 45 ° |
vergrotingsbereik | van 800x tot 1280X |
oculair buisdiameter, mm / td> |
30 |
Doelstellingen | Infinity Plan Achromatic: PL L5X/0.12, PL L10X/0.25, PL L20X/0.40, PL L50X/ 0.70, PL L100X/0.85 (DROGE) Parfocale afstand 45 mm (*Optie: PL L40X/0.60, PL L60X/0.70, PL L80X/0.80) |
Revolving Nosepiece | voor 5 doelstellingen |
werkafstand, mm | 26.1 (5x) 20.2 (10x) 3.98 (40x) 2.08 (60x) 8,80 ( 20x) 3.68 (50x) 1,25 (80x) 0.40 (100x) |
interpupillaire afstand, mm | 48 - 75 |
Stage, MM | 242x200 |
Stage Moving Range, MM | 30/30 |
diafragm | ingebouwd diafragma en veld |
focus | coaxiaal, grof (grof (grof met grove focusspanningsaanpassing en een slotknop) en fijn (0,002 mm) |
helderheidsaanpassing | ja |
< TR> Lichtbrontype | 12v/30W | Bedrijfstemperatuurbereik, ° C | 5 - 35 td> |
Montage- en installatieproblemen Level | gecompliceerd |
verlichtingslocatie | lager < /td> |
sensor | sony exmor/starvis cmos |
color/monochrome | Kleur |
megapixels | 2 |
maximale resolutie, pix | 1920x1080 |
sensorgrootte | 1/2 '(7.2x4.05mm) |
pixel maat, μm | 3.75x3.75 |
lichtgevoeligheid | 1175mv met 1/30s |
signaal/ruisverhouding | 0,15 mV bij 1/30S |
Blootstellingstijd | 0,04ms - 1000ms |
Video -opname | ja |
afbeeldingsformaat | *. JPG, * .tif |
Spectral Range, NM | 380–650 (ingebouwd IR-filter) |
Sluittype | ers (elektronische rollenter) |
systeemvereisten | Windows 8/10/11 (32bit en 64bit) , Mac OS X, Linux, tot 2,8 GHz Intel Core 2 of hoger, minimaal 4 GB RAM, USB2.0-poort, RJ45, CD-ROM, 19 'of groter display |
Mount Type | c-mount |
camera voeding | dc adapter 12v, 1A |
Camera bedrijfstemperatuurbereik, ° с | -10-50 |
Bedrijfsvochtigheidsbereik, % | 30-80 |
software | hdmi: ingebouwde USB: magus view |
type < /td> |
licht/optisch, digitaal, metallurgisch |
Nozzle | siedentopf, roteerbaar 180 ° |
vergroting, x | 50–1000 BASIC (*Optioneel: 50–1250/1500/2000/2500) |
oceers | 10х/22 mm, oogverlichting: 10 mm (*Optioneel: 10x/22 mm met schaal, 12,5x/14 15x/15 20x/12 25x/9) |
Stage Functies | Twee-as mechanisch, ronde roterende podiumplaat Ø130 mm met gaten Ø10 mm, Ø20 mm en Ø30mm |
Illumination | halogeen < /td> |
voeding | 220 ± 22V, 50Hz, AC Network |
lichtfilters | groen, blauw, geel, mat |
extra | Verwijderbare analysator en polarisizer |
Gebruikersniveau | ervaren gebruikers, professionals |
Toepassing | Metallurgical |
Onderzoeksmethode | Bright Field, polarisatie |
pouch/case/tas in set | stofomslag |
interface -connectoren | USB 2.0, HDMI 1.4 |
geheugenkaart | SD tot 32 GB |
Mogelijkheid om extra apparatuur aan te sluiten | USB -muis, flashstick (USB) |
framesnelheid, FPS, FPS, FPS, FPS bij resolutie | 60@1920x1080 (HDMI), 50@1920x1080 (USB) |
Plaats van installatie | trinoculaire buis, oepula buis in plaats van een oculair |
Video -indeling | *. H264/*. H265,*.mp4 |
body | cnc aluminium legering |
Specificaties van de DC Power Adapter | Input: AC Voltage 100–240V, 50 /60Hz, uitgang: DC -spanning 12v/1A |
=== Delimiter === | Monitor Specificaties |
Type matrix | ips |
display diagonal, inch | 13.3 |
< TR> Display Resolution, PX | 1920x1080 (Full HD) |
Aspectverhouding | 16: 9 |
helderheid, cd/m² | 400 |
nummer van weergegeven kleuren | 16.7 M |
contrast | 1000: 1 |
horizontale/verticale kijkhoek, ° | 178/178 |
Grootte van het zichtbare schermgebied (wxh), mm | 295x165 |
pixel pitch (wxh), mm | 0.154x0.154 |
frequentie van optische bron, hz | 60 |
Type matrix achtergrondverlichting | led |
LED -achtergrondverlichting Lifetime, H | < td> 50000
interface | hdmi |
bedrijfstemperatuurbereik, ° C | -15-55 |
Bedrijfsvochtbereik, % | 10-90 |
Voeding | AC 110–220V, DC 5–12V/1A (Type-C) |
stroomverbruik, W | 12 (max.) |
